RIBPRO

Andrés RIBPRO are made heavy duty and rigid to resist heat and rain for all types of extreme applications. Prime grade high strength steel combined with step rib design allows RIBPRO to withstand heavier live loads. With minimal maintenance costs, RIBPRO is ideal for all types of residential, commercial, and institutional roofing applications, including factories and warehouses.

1. Ensure the roof truss has a minimum slope of 100.
2. Install purlins with 300mm spacing between the first and second purlins and 600-800mm
spacing for the remaining purlins.
3. Lay roofing sheets starting from the eave and working toward the ridge.
4. Align the first sheet squarely with the roof edge before fastening.
5. Maintain a minimum of 150mm end overlap.
6. Provide a side overlap of at least one full rib.
7. Select the appropriate Tekscrew based on the purlins material, whether wood or metal.
8. Fasten sheets at the recommended locations without over tightening the screws.
9. Install ridge rolls and flashings, ensuring proper overlaps to prevent water leakage.
10. Remove all metal fillings, loose screws, and debris after installation.
