Profile Planks

Philippine houses in the past were clad with beautiful timber stone-cut or s-cut sidings that were favored by architects, designers, and home owners alike. Unfortunately, these sidings were prone to damage from termites and rot fungus. With GARDNER TPI Profile Planks, which are termite and rot resistant, homeowners can now enjoy the elegant wall grooves without worrying about these issues.

Profile Planks are an excellent substitute for timber stone-cut and provide a stunning wood-like appearance when stained. GARDNER TPI Profile Planks are available in different widths, with an option to combine different Profile Plank widths to achieve a variety of wall effects. GARDNER TPI Profile Planks are excellent for cladding interior and exterior walls.

SPECIFICATIONS

GARDNER TPI Profile Planks are available in both Modern Cut and Stone Cut profiles. Modern Cut Profile Plankscome in 100mm, 150mm, and 200mm widths with 10mm thickness and 3000mm lengths, uncolored and with straight grain texture. Stone Cut Profile Plankscome in 150mm widths with 10mm thickness and 3000mm lengths, uncolored and with cassia texture.

Profile Plank Installation

Lay out
Plank overlaps at 20mm stone cut, 18mm modern cut

Frame Type
Galvanized Frames (0.5mm or 0.6mm Thick Studs and Tracks) Treated Wood Frames (2×4)

Frame Spacing
0.6m maximum

Screw
GF Screw (G.I.), WF Screw (wood) spaced 0.6m for every stud spacing. Screw 12mm from edge of plank



Profile Plank Product Installation 4
