Floor Board

Gardner TPI Floor Boards are durable, resilient, and tough boards for raised floors. They are specifically engineered to carry heavy loads and level floors. Depending on the spacing of the joist, Floor Boards can support loads of up to 2900kg/sqm. (Refer to the table below for the different loads 16mm and 18mm Floor Boards can carry when supported by joists with spacings at 0.3m, 0.4m, and 0.6m.)

Gardner TPI Floor Boards are particularly well-suited for upper floors where weight-bearing capacity is a factor. Floor Boards can be installed much faster and easier than reinforced concrete slabs. GARDNER TPI Floors Boards are ideal for upper floor areas in residences, factories, warehouses, stores, and farms.

SPECIFICATIONS

GARDNER TPI Floor Boards come in 4ft x 8ft (1220mm x 2440mm) sizes with thicknesses available at 16mm and 18mm. Floor Boards come uncolored with a smooth surface.

Floor Installation

Frame Type
Steel Frames (2.5mm thk Tubular, 2mm thk C-Purlin Frames)
Treated Wood Frames (2×6)
Size and span of the frames should be designed to carry the appropriate load.

Frame Spacing
0.3m x 0.3m, 0.4m x 0.4m, 0.6m x 0.6m (max)

Screw
SF Screw (steel), WF Screw (wood)
