Geigher
Delta Frames

Delta Frames

GEIGHER Delta Frames are designed for large areas such as hotels, restaurants, and huge offices. Delta Double Furring and Single Furring are especially designed with a side recess to provide a more stable and sturdy frame. Delta Wall Angles have ends that are bended for safety against cut and for better handling. Combined with the extra corrosion and moisture protection of the gold resin layer, this makes Delta Frames the GOLD standard in ceiling systems.

SPECIFICATIONS

Delta Frames Product Photo

Delta Installation

Layout and attach wall angle to the perimeter wall

Space DOUBLE FURRING Furring at 406 to 610mm and connect to Wall Angle

Space CARRYING CHANNEL at 1000 to 1200mm and connect to Alpha Clip

Attach J-Hanger Clip to threaded rod to expansion shield to slab spaced at 1000 to 1200mm

Attach ceiling board with ficem/gypsum screw

Delta Frames Product Installation
